36 Configuration Guides—XT-9100 Configuration Guide
RI. HI. Type R/W Tag Description
104 68 2 Bytes CNF AIT3 Input Type of Analog Input 3
(bits as AIT1)
105 69 Number CNF HR3 High Range Analog Input 3
106 6A Number CNF LR3 Low Range Analog Input 3
107 6B Number R/W (E) HIA3 High Alarm Limit Analog Input 3
108 6C Number R/W (E) LOA3 Low Alarm Limit Analog Input 3
109 6D Number R/W (E) ADF3 Differential on Alarm Limit [units]
110 6E Number CNF FTC3 Filter Constant Analog Input 3
111 6F 2 Bytes Spare
112 70 2 Bytes CNF AIT4 Input Type of Analog Input 4
(bits as AIT1)
113 71 Number CNF HR4 High Range Analog Input 4
114 72 Number CNF LR4 Low Range Analog Input 4
115 73 Number R/W (E) HIA4 High Alarm Limit Analog Input 4
116 74 Number R/W (E) LOA4 Low Alarm Limit Analog Input 4
117 75 Number R/W (E) ADF4 Differential on Alarm Limit [units]
118 76 Number CNF FTC4 Filter Constant Analog Input 4
119 78 2 Bytes Spare
120 74 2 Bytes CNF AIT5 Input Type of Analog Input 5
(bits as AIT1)
121 79 Number CNF HR5 High Range Analog Input 5
122 7A Number CNF LR5 Low Range Analog Input 5
123 7B Number R/W (E) HIA5 High Alarm Limit Analog Input 5
124 7C Number R/W (E) LOA5 Low Alarm Limit Analog Input 5
125 7D Number R/W (E) ADF5 Differential on Alarm Limit [units]
126 7E Number CNF FTC5 Filter Constant Analog Input 5
127 7F 2 Bytes Spare
