Configuration Guides—XT-9100 Configuration Guide 37
RI. HI. Type R/W Tag Description
128 80 2 Bytes CNF AIT6 Input Type of Analog Input 6
(bits as AIT1)
129 81 Number CNF HR6 High Range Analog Input 6
130 82 Number CNF LR6 Low Range Analog Input 6
131 83 Number R/W (E) HIA6 High Alarm Limit Analog Input 6
132 84 Number R/W (E) LOA6 Low Alarm Limit Analog Input 6
133 85 Number R/W (E) ADF6 Differential on Alarm Limit [units]
134 86 Number CNF FTC6 Filter Constant Analog Input 6
135 87 2 Bytes Spare
136 88 2 Bytes CNF AIT7 Input Type of Analog Input 7
(bits as AIT1)
137 89 Number CNF HR7 High Range Analog Input 7
138 8A Number CNF LR7 Low Range Analog Input 7
139 8B Number R/W (E) HIA7 High Alarm Limit Analog Input 7
140 8C Number R/W (E) LOA7 Low Alarm Limit Analog Input 7
141 8D Number R/W (E) ADF7 Differential on Alarm Limit [units]
142 8E Number CNF FTC7 Filter Constant Analog Input 7
143 8F 2 Bytes Spare
144 90 2 Bytes CNF AIT8 Input Type of Analog Input 8
(bits as AIT1)
145 91 Number CNF HR8 High Range Analog Input 8
146 92 Number CNF LR8 Low Range Analog Input 8
147 93 Number R/W (E) HIA8 High Alarm Limit Analog Input 8
148 94 Number R/W (E) LOA8 Low Alarm Limit Analog Input 8
149 95 Number R/W (E) ADF8 Differential on Alarm Limit [units]
150 96 Number CNF FTC8 Filter Constant Analog Input 8
151 97 2 Bytes Spare
