Fan Size (Inch) 18 X 15 18 X 15
Type Centrifugal Centrifugal
Motor Sheave 1VP60 1VP60 1VP60 1VP60
Blower Sheave BK120 BK100 BK110 BK090
Belt BX81 BX78 BX78 BX75
Motor HP each 5 7.5 7.5 10
RPM 1750 1750 1750 1760
Frame size 184T 213T 213T 215T
FILTERS
Quantity - Size
4 - (16 x 25 x 2),
12 - (12 x 24 x 2)
1,2
4 - (16 x 20 x 2)
1,2
4 - (16 x 25 x 4),
2 - (20 x 24 x 4),
12 - (12x 24 x 4)
3
4 - (16 x 20 x 4)
3
1. 2 In. Throwaway, Standard, MERV (Minimum Efficiency Reporting Value) 3.
2. 2 In. Pleated, Optional, MERV 8.
3. 4 In. Pleated, Optional, MERV 13.
Table 7: J15/20XP Physical Data (Continued)
Component
Models
J15XP J20XP
Nominal Tonnage 15 20

Johnson Controls York 20 Series Specifications

General

Brand	Johnson Controls
Model	York 20 Series
Category	Heating System
Language	English
