Johnson Controls ZE Series User Manual

6021974-UIM-A-1120
Johnson Controls Ducted Systems 27
ZE036-060 - With Powered Convenience Outlet (Direct Drive)
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Conv
Outlet
Electric Heat Accessory
MCA
1
(Amps)
Max Fuse
2
/
Breaker
3
Size
(Amps)
RLA LRA MCC FLA FLA FLA Model kW Stages Amps
036
(3.0)
208-1-60 15.4 83.9 24 2.3 6 10
NONE - - - 37.5 50
E05 4 1 19.2 44 50
E07 5.6 1 26.9 53.7 60
E10 8 1 38.5 68.1 70
E15 11.9 2 57.2 91.5 100
E20 15.9 2 76.4 115.6 125
230-1-60 15.4 83.9 24 2.3 6 10
NONE - - - 37.5 50
E05 5.3 1 22.1 47.6 50
E07 7.5 1 31.2 59.1 60
E10 10.6 1 44.2 75.2 80
E15 15.9 2 66.2 102.8 110
E20 21.2 2 88.3 130.4 150
208-3-60 10.4 73 16.3 2.3 6 10
NONE - - - 31.3 40
E05 4 1 11.1 33.9 40
E07 5.6 1 15.5 39.4 40
E10 8 1 22.2 47.8 50
E15 11.9 2 33 61.3 70
E20 15.9 2 44.1 75.2 80
230-3-60 10.4 73 16.3 2.3 6 10
NONE - - - 31.3 40
E05 5.3 1 12.7 35.9 40
E07 7.5 1 18 42.6 45
E10 10.6 1 25.5 51.9 60
E15 15.9 2 38.2 67.8 70
E20 21.2 2 51 83.7 90
048
(4.0)
208-1-60 19.6 130 30.5 2.3 7.6 10
NONE - - - 44.4 60
E05 4 1 19.2 46 60
E07 5.6 1 26.9 55.7 60
E10 8 1 38.5 70.1 80
E15 11.9 2 57.2 93.5 100
E20 15.9 2 76.4 117.6 125
230-1-60 19.6 130 30.5 2.3 7.6 10
NONE - - - 44.4 60
E05 5.3 1 22.1 49.6 60
E07 7.5 1 31.2 61.1 70
E10 10.6 1 44.2 77.2 80
E15 15.9 2 66.2 104.8 110
E20 21.2 2 88.3 132.4 150
208-3-60 13.7 83.1 21.4 2.3 7.6 10
NONE - - - 37 45
E05 4 1 11.1 37 45
E07 5.6 1 15.5 41.4 50
E10 8 1 22.2 49.8 50
E15 11.9 2 33 63.3 70
E20 15.9 2 44.1 77.2 80
230-3-60 13.7 83.1 21.4 2.3 7.6 10
NONE - - - 37 45
E05 5.3 1 12.7 37.9 50
E07 7.5 1 18 44.6 50
E10 10.6 1 25.5 53.9 60
E15 15.9 2 38.2 69.8 70
E20 21.2 2 51 85.7 90
