Johnson Controls ZE Series User Manual

6021974-UIM-A-1120
Johnson Controls Ducted Systems 61
Table 29: ZE060 (5.0 Ton) Operating Pressures
Air Flow
Indoor Db/Wb
Indoor
DB/WB
Outdoor
DB
Suction
Pressure
Suction
Temp.
Liquid
Pressure
Liquid
Temp.
Delta T
Db
Entering
Evap Db
Leaving
Evap Db
Compressor
Amps
300 Cfm/Ton 80/62
75 123 52 283 77 -30 80 50 14
85 126 53 329 85 -29 80 51 16
95 130 55 381 94 -27 80 53 19
300 Cfm/Ton 80/67
75 135 58 289 79 -24 80 56 14
85 138 58 335 86 -24 80 56 17
95 143 60 387 95 -22 80 58 19
300 Cfm/Ton 80/72
75 147 64 294 80 -19 80 61 15
85 150 64 340 88 -19 80 61 17
95 153 66 392 95 -18 80 62 19
300 Cfm/Ton 75/63
75 124 54 283 76 -24 75 51 14
85 128 55 329 84 -23 75 52 16
95 132 56 382 94 -22 75 53 19
400 Cfm/Ton 80/62
75 130 56 285 78 -26 80 54 14
85 133 57 331 86 -25 80 55 16
95 139 59 382 95 -24 80 56 19
400 Cfm/Ton 80/67
75 141 60 292 79 -21 80 59 15
85 144 61 339 87 -20 80 60 17
95 147 62 390 95 -20 80 60 19
400 Cfm/Ton 80/72
75 152 67 297 80 -16 80 64 15
85 156 67 342 88 -16 80 64 17
95 160 67 396 96 -15 80 65 20
400 Cfm/Ton 75/63
75 132 56 287 77 -20 75 55 14
85 134 57 334 85 -20 75 55 17
95 138 58 386 94 -19 75 56 19
Table 30: ZE072 (6.0 Ton) Operating Pressures
Air Flow
Indoor Db/Wb
Indoor
DB/WB
Outdoor
DB
Suction
Pressure
Suction
Temp.
Liquid
Pressure
Liquid
Temp.
Delta T
Db
Entering
Evap Db
Leaving
Evap Db
Compressor
Amps
300 Cfm/Ton 80/62
75 129 58 304 137 -24 80
56
12.0
85 128 54 352 148 -24 80
56
13.4
95 128 50 399 159 -25 80
55
14.7
300 Cfm/Ton 80/67
75 128 60 304 137 -24 80
56
12.0
85 131 59 356 151 -23 80
57
13.5
95 133 58 408 164 -22 80
58
15.0
300 Cfm/Ton 80/72
75 127 62 305 137 -24 80
56
12.0
85 132 64 361 153 -21 80
59
13.6
95 138 66 416 169 -19 80
61
15.3
300 Cfm/Ton 75/62
75 123 56 302 137 -21 75
54
11.9
85 124 51 350 148 -21 75
54
13.3
95 125 47 399 158 -21 75
54
14.8
400 Cfm/Ton 80/62
75 134 58 304 133 -21 80
59
11.8
85 135 57 353 146 -21 80
59
13.3
95 136 55 402 158 -21 80
59
14.8
400 Cfm/Ton 80/67
75 135 59 305 134 -21 80
59
11.9
85 137 59 357 148 -20 80
60
13.4
95 139 59 408 161 -19 80
61
14.9
400 Cfm/Ton 80/72
75 135 60 307 134 -21 80
59
11.9
85 138 62 360 149 -19 80
61
13.5
95 141 64 413 164 -18 80
62
15.1
400 Cfm/Ton 75/62
75 128 55 302 134 -19 75
56
11.8
85 130 54 352 146 -18 75
57
13.3
95 132 52 402 159 -18 75
57
14.8
