ZE036 - 060 (3-5 Ton Direct Drive) Bottom Duct
UNIT
TONNAGE
MOTOR
1
SPEED
1. Factory set on medium speed tap.
AVAILABLE EXTERNAL STATIC PRESSURE - IWG
2
2. Includes allowances for a wet evaporator coil, 1” filters, and the heat exchangers. Refer to STATIC RESISTANCES Table for resistance
values.
0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
CFM
WATTS
3
3
3. Bottom Duct application (230 Volts)
5 (HI) 1520 320 1478 335 1438 349 1401 363 1363 376 1327 390 1286 403 1248 417 1207 430
4 (MED/HI) 1430 263 1384 276 1342 290 1302 303 1259 316 1215 329 1168 343 1114 358 1044 374
3 (MED) 1287 208 1242 221 1199 234 1155 246 1108 258 1060 272 997 288 930 303 889 313
2 (MED/LOW) 1185 171 1138 183 1091 195 1041 207 987 220 921 235 862 248 - - - -
1 (LOW) 1040 130 959 134 900 145 - - - - - - - -----
4
3
5 (HI) - - 1995 696 1957 714 1922 734 1885 749 1844 764 1795 769 1709 743 1566 685
4 (MED/HI) 1846 539 1812 557 1776 571 1736 585 1704 602 1662 619 1619 638 1566 653 1492 639
3 (MED) 1662 408 1624 426 1577 438 1542 455 1501 472 1454 490 1400 505 1356 521 1323 536
2 (MED/LOW) 1566 362 1526 380 1480 391 1450 406 1411 423 1363 440 1312 455 1279 469 1235 485
1 (LOW) 1287 223 1246 237 1190 247 - - - - - - - -----
5
3
5 (HI) 2166 883 2169 931 2158 950 2134 964 2095 979 2040 971 1963 940 1881 898 1791 854
4 (MED/HI) 2060 771 2042 784 2035 808 2006 826 1970 844 1934 859 1888 861 1821 843 1730 806
3 (MED) 1940 637 1920 656 1907 675 1870 696 1834 715 1802 730 1759 740 1722 756 1657 748
2 (MED/LOW) 1688 413 1645 432 1611 451 1575 468 1534 479 1498 497 1461 513 - - - -
1 (LOW) 1509 327 1477 339 - - - - - - - - - -----
Table 17: Belt Drive RPM Selection
Size
(Tons)
Model HP
Max
BHP
Motor
Sheave
Blower
Sheave
5 Turns
Open
4 Turns
Open
3 Turns
Open
2 Turns
Open
1 Turn
Open
Fully
Closed
036
(3)
ZE
1.5 1.73 1VL44 AK64 805 865 920 980 1035 1095
1.5 1.73 1VP56 AK66 1115 1170 1225 1280 1335 1390
048
(4)
ZE
1.5 1.73 1VL44 AK56 930 995 1060 1130 1195 1260
1.5 1.73 1VP56 AK61 1210 1270 1330 1390 1455 1515
060
(5)
ZE
1.5 1.73 1VL44 AK56 930 995 1060 1130 1195 1260
2 2.3 1VP56 AK56 1325 1395 1460 1525 1590 1660
072
(6)
ZE
1.5 1.73 1VL44 AK56 930 995 1060 1130 1195 1260
3 3.45 1VP56 AK56 1325 1395 1460 1525 1590 1660
Table 18: Indoor Blower Specifications (Belt Drive)
Size
(Tons)
Motor Motor Sheave Blower Sheave
Belt
HP RPM Eff. SF Frame
Datum Dia.
(in.)
Bore (in.) Model
Datum Dia.
(in.)
Bore (in.) Model
036
(3.0)
1-1/2 1725 0.8 1.15 56 2.8 - 3.8 7/8 1VL44 6.0 1 AK64 A37
1-1/2 1725 0.8 1.15 56 4.0 - 5.0 7/8 1VP56 6.2 1 AK66 A39
048
(4.0)
1-1/2 1725 0.8 1.15 56 2.8 - 3.8 7/8 1VL44 5.2 1 AK56 A36
1-1/2 1725 0.8 1.15 56 4.0 - 5.0 7/8 1VP56 5.7 1 AK61 A38
060
(5.0)
1-1/2 1725 0.8 1.15 56 2.8 - 3.8 7/8 1VL44 5.2 1 AK56 A36
2 1725 0.8 1.15 56 4.0 - 5.0 7/8 1VP56 5.2 1 AK56 A38
072
(6.0)
1-1/2 1725 0.8 1.15 56 2.8 - 3.8 7/8 1VL44 5.2 1 AK56 A36
3 1725 0.8 1.15 56 4.0 - 5.0 7/8 1VP56 5.2 1 AK56 A38
Table 19: Power Exhaust Specifications
Model Voltage
Motor Motor
Fuse
Size
CFM @
0.1 ESP
HP RPM QTY LRA FLA MCA
2PE04703725 208/230-1-60 1/2 1725
1
1. Motors are multi-tapped and factory wired for high speed.
1 23.7 4.4 5.5 8 1350
2PE04703746 460-1-60 1/2 1725
1
1 4.1 1.7 2.1 5 1350
2PE04703758 575-3-60 1/2 1725 1 4.5 0.9 1.1 2 1350
