6021974-UIM-A-1120
Johnson Controls Ducted Systems 31
Fins per inch 13 13 13 13
Tube diameter 0.375 0.375 0.375 0.375
Circuitry Type Intertwined Intertwined Intertwined Intertwined
Refrigerant control Orifice Orifice TXV TXV
CONDENSER FAN DATA
Quantity of fans 1 1 1 1
Fan diameter (Inch) 24 24 24 24
Type Prop Prop Prop Prop
Drive type Direct Direct Direct Direct
Quantity of motors 1 1 1 1
Motor HP each 1/2 1/2 1/2
3
1/2
4
No. speeds 1 1 1 2
RPM 1090 1090 1100 900 / 1150
CFM 4000 4000 4200 3300 / 4200
BELT DRIVE EVAP FAN DATA
Quantity 1 1 1 1
Fan Size (Inch) 11 x 10 11 x 10 11 x 10 11 x 10
Type Centrifugal Centrifugal Centrifugal Centrifugal
Motor Sheave 1VL44 1VP56 1VL44 1VP56 1VL44 1VP56 VL44 1VP56
Blower Sheave AK64 AK66 AK56 AK61 AK56 AK56 AK56 AK56
Belt A37 A39 A36 A38 A36 A38 A36 A38
Motor HP each 1-1/2 1-1/2 1-1/2 1-1/2 1-1/2 2 1-1/2 3
RPM 1740 1740 1740 1740
Frame size 56 56 56 56
DIRECT DRIVE EVAP FAN DATA
5
Quantity 1 1 1 -
Fan Size (Inch) 11 x 10 11 x 10 11 x 10 -
Type Centrifugal Centrifugal Centrifugal -
Motor HP each 3/4 1 1 -
RPM 1050 1050 1050 -
FILTERS
15" x 20" x 1" or 2" 2 2 2 2
14" x 25" x 1" or 2" 1 1 1 1
1. Cooling Only Unit
2. Cooling Unit with Gas Heat
3. FER or Fan Energy Rating is a Department of Energy (DOE) requirement for single phase gas/electric product rated 65K or less of cooling
capacity. DOE ruling effective 7/2019.
4. ECM O.D. Fan Motor
5. Only Available On 208/230 Volt Models
ZE036-072 Physical Data (Continued)
Component
Models
ZE036 ZE048 ZE060 ZE072
Nominal Tonnage 3 4 5 6
