©2011 Johnson Level & Tool 13
2. Press the slope mode button again to select Y-direction slope.
- Press the button pointing to the left to shift the slope angle to
the left.
- Press the button pointing to the right to shift the slope angle to
the right.
3. Another press of the slope mode button changes back to
X-direction slope selection. Pressing and holding the button returns
the unit to normal operation.
4. Hold the slope mode button in for three seconds to enter single slope
mode. X is the default axis. The X-axis LED is on and the Y-axis LED is
flashing. Push the slope button again to slope the Y-axis. The laser will
continue to self-level in this mode. Pressing and holding the button
returns the unit to normal operation.
Notes:
• When the unit is in TILT mode, pressing the slope mode button and
entering the dual axis mode will exit you from the TILT mode and into
the slope mode.
• When using the laser in the single slope mode, the TILT feature
can be used. When using the slope mode in Y-direction the verti-
cal beam can be moved to the left or right.
Timed Auto-off Function
Turn the unit on using the power button on the laser keypad. Press the
power button once on the remote control. The unit is now in sleep
mode. The rotating beacon and laser beam will be powered down.
If the unit is in sleep mode for 30 continuous minutes, the unit turns off
automatically. With a second press of the power button on remote control,
the unit exits sleep mode and enters self-level mode.
4411H-English_Manuals 3/11/11 1:13 PM Page 13
