9. Technical Specifications
Laser Wavelength 635nm±10nm (Model 40-6526 & 40-6529)
532nm±10nm (Model 40-6544)
Laser Classification Class IIIa
Maximum Power Output ≤5mW
Accuracy ±1/8”/100 ft. (±1.0mm/10m)
Interior Range Up to 200 ft. diameter (60m)
depending upon light conditions
(Model 40-6526 & 40-6529)
Up to 400 ft. diameter (120m)
depending upon light conditions
(Model 40-6544)
Exterior Range Up to 1500 ft. diameter (500m)
with red detector (not included in 40-6526)
Up to 1200 ft. diameter (400m)
with green detector (not included)
Remote Range Up to 200 ft. diameter (60m) with remote
Slope ±5°
Self-Leveling Range ±5°
