©2013 Johnson Level & Tool - Rev. 1 5
5. Location of Part/Components
Laser output
window
Battery-case
locking screw
Remote control
input receivers
Keypad
Vertical adjustment knob
Battery case
5/8" thread holes
Transportation
locking knob
Calibration
screw plug
Handle and
vertical bracket
7365H-All_Manuals 10/14/13 2:53 PM Page 5
