10. Technical Specifications
Laser Wavelength 635 nm (40-6603 & 40-6605)
Laser Wavelength 520 nm (40-6601)
Laser Classification II
Maximum Power Output ≤1mW
Self-Leveling Range ±4°
Laser Accuracy
±3/16″/ 30 ′
Measuring Range 0′ - 30′
Power Supply 2 “AA” alkaline batteries (included)
Battery Life* 36 hours/20 hours (40-6603 & 40-6605)
16 hours/9 hours (40-6601)
Operating
Temperature Range 32°F - 104°F
Storage
Temperature Range 0°F - 120°F
Dimensions 3
″ x 3 ″ x 2.37 ″
Weight 0.53 lbs
Tripod Thread 1/4″ – 20
IP Rating IP 50
* Battery life reported with all beams enabled, as tested with lithium
AA/Alkaline AA.
