Johnson E7000 User Manual

ASSEMBLY INSTRUCTIONS
To ensure the correct assembly of the E7000, please carefully follow these steps:
ASSEMBLY
Handlebar(L)
Sensor Cable
Console Mast
Handlebar(R)
Base Frame
Front Stabilizer
Console Mast Boot
Link Arm(L)
Link Arm(R)
Console
FASTENERS & ASSEMBLY TOOLS
PARTS NO. DESCRIPTION
QUANTITY
Z01
Z02
Z03
Z04
Z05
Z06
Z07
Z08
Z10
Z11
Z13
Z14
Z15
Z17
Z18
Z19
Z20
Z21
C51
C53
C54
C55
Hex Head Screw (M8x12L)
Washer (ø8.2xø16x1.4t)
Hex Head Screw (M8x85L)
Washer (ø8.2xø16x2.0t)
Bushing
Buttonhead Bolt (M8x35L)
Nylon Nut (M8x1.25P)
Link Arm Cap
Buttonhead Screw (M8x20L)
Buttonhead Screw (ø4x16L)
M8 Allen Key
M6 Allen Key
M5 Allen Key
Open Wrench (#13)
Hex Head Screw (M6x20L)
Phillips Driver
T-Type Wrench (M6)
Close Wrench (#13,#14,#15)
Cross-head Screw (M5x10L)
Hex Head Screw (M5x12L)
Washer (ø5.3xø10x1.0t)
Spring Washer (ø5.1xø9.3x1.3t)
8
8
2
2
4
2
4
4
2
4
1
1
1
1
8
1
1
1
2
2
2
2
0706
JOHNSON ELLIPTICAL E7000JOHNSON ELLIPTICAL E7000
SKETCH
ASSEMBLY DIAGRAM
Handlebar Cap
