Johnson E7000 User Manual

Front Stabilizer
Z10
0908
JOHNSON ELLIPTICAL E7000JOHNSON ELLIPTICAL E7000
STEP 1 STEP 2
1). Lift up the Main Body at the front end. Ask your assistant to insert the wooden or
hard box underneath the Main Body while you lift up the Main Body.
2). Fasten the Front Stabilizer to the Main Body by using Buttonhead Screws (Z10).
1). Thread the Console Mast through the Console Mast Boot.
2). Feed the cable through the Console Mast. Tape the cable to the top of the Console
Mast to secure it temporarily.
3). Attach the Console Mast to the Base Frame using Hex Head Screws (Z03), Washers
(Z04) and Nylon Nut (Z07). Ask your assistant to hold the Console Mast while
tighten screws.
4). Attach the Bottle Holder Rack to the Console Mast using Cross-head Screws (C51)
and Washers (C54).
Console Mast
Console Mast Boot
Sensor Cable
Bottle Holder Rack
C51
Z07
Z04
Z03

Johnson E7000 Specifications

General

Brand	Johnson
Model	E7000
Category	Elliptical Trainer
Language	English
