CONSOLE REPLACEMENT PROCEDURE (5100series)
Tools required:
u Philips
screwdriver
Procedure:
1. Loosen the screws (arrow) from the console using the
screwdriver.
2. Disconnect the console
cables from the console
connectors.
3. Replace the console
with a new one and
reconnect the console cable to the connector.
4. Tighten the screws that hold the console to the bracket.
3-1 Revision: 1.0 Date: 2001/06/01
