Johnson JPB-5100 - SEAT REPLACEMENT PROCEDURE (JAR)

SEAT REPLACEMENT PROCEDURE (JAR)
Tools required:
u Philips
screwdriver
u Open-end wrench
(13mm)
Procedure:
1. Remove the bolt from
the seat roller by
using the open-end
wrench (13mm) then
remove the seat
2. Loosen the screws
holding the seat to the
bracket.
3. Replace the seat with a
new one
4. Reverse step 1-2 to
install all the parts
3-29 Revision: 1.0 Date: 2001/06/01
