PEDAL AXLE-PULLEY ASSEMBLY REPLACEMENT
PROCEDURE (JPC/B)
Tools required:
u Philips
screwdriver
u C-clip pliers
u Crank extractor
u Coin
u Hex key (4mm)
u Open-end
wrench
(14&17 mm)
Procedure:
5. Remove the c-clip (C) by using the c-clip pliers and
remove the metal pulley from the generator using the
Bearing Puller.
6. Remove the c-clip (D) by using the c-clip pliers and
remove the idler using the Bearing Puller.
7. Remove the c-clip (B) by using the c-clip pliers and
remove the Bearing Housing using the Bearing Puller.
8. Replace the axle-pulley assembly with a new one.
9. Reverse step 1-9 to install the parts.
