Johnson T7000 PRO User Manual

ASSEMBLY INSTRUCTIONS
0908
T R E A D M I L L T 7 0 0 0 P R O T R E A D M I L L T 7 0 0 0 P R O
Please make sure that the power plug is not plugged into the wall outlet while assembling
the treadmill. Ensure correct assembly of the T7000 PRO, carefully read and follow these steps:
ASSEMBLY EXPLODED DIAGRAM
Z50
Z50
Z50
Z51
Z54*2
Z56*2
Z54*4
Z55*4
P23
C01
C02
Z53
Z53
FASTENERS
PART NO. DESCRIPTION SKETCH QUANTITY NOTE
HEX SOCKET THIN HEAD SCREW(
M8*1.5P*15L
)
Z50
Z51
Z5 3
Z5 4
Z5 5
Z5 6
HEX SOCKET HEAD SCREW(M10*1.5P*20L)
FLAT WASHER (Ø10.5*Ø18*2.0T)
PHILLIP BUTTON HEAD SCREW(M5*0.8P*12L)
WHITE
WHITE
BLACK/
YELLOW
BLUE
BLUE
BLUE
RED
RED
RED
10
6
4
10
2
2
1
1
1
ARC WASHER (Ø8.2*Ø18*1.5T)
ARC
SADDLE TYPE TIE MOUNT (HC-4 KSS)
RELEASIBLE CABLE TIE (HV150HB KSS)
PHILLIP ROUND HEAD SCREW (M5*0.8P*20L)
WASHER(Ø10.2*Ø20*1.5T)
Z62
Z63
Z64
