INSTALLATION PRECAUTIONS
Note: This table is only for reference, the installation shall meet the requirements of local laws
and regulations.
Torque Parameters
PIPE Size
1/4 ( 6.35)
3/8 ( 9.52)
1/2 ( 12)
5/8 ( 15.88)
Newton meter[N x m]
18 - 20
30 - 35
45 - 50
60 - 65
Pound-force foot (1bf-ft) Kilogram-force meter (kgf-m)
24.4 - 27.1
40.6 - 47.4
61.0 - 67.7
81.3 - 88.1
2.4 - 2.7
4.1 - 4.8
6.2 - 6.9
8.2 - 8.9
Dedicated Distribution Device and Wire for Air Conditioner
Pipe Length and Additional Refrigerant
Inverter Models Capacity (Btu/h)
9K-12K 18K-24K
Lenght of pipe with standard charge
Maximum distance between indoor and outdoor unit
Additional refrigerant charge
Max. diff. in level between indoor and outdoor unit
Type of refrigerant
R32
25m
10m
15g/m
R32
25m
10m
25g/m
5m 5m
9k
12k
18k
24k
Power supply cable
Connection cable
N
L or (L)
1
N
L
sectional area
2
1.5mm
2
2.5mm
2
1.5mm
2
1.5mm
INVERTER TYPE
MODEL capacity (Btu/h)
2
0.75mm
2
0.75mm
2
0.75mm
2
1.5mm
2
2.5mm
2
1.5mm
2
1.5mm
2
1.5mm
2
2.5mm
2
1.5mm
2
1.5mm
2
0.75mm
2
0.75mm
2
0.75mm
2
0.75mm
2
0.75mm
2
0.75mm
2
0.75mm
2
0.75mm
2
0.75mm
2
0.75mm
2
0.75mm
2
0.75mm
2
0.75mm
