Parts List
Make sure all parts are available before assembly. If any part is missing,
please contact local retailer. No tools are required for assembly.
Fig. 1.1 Head Support Fig. 1.10 Lock-off Device
Fig. 1.2 Seat Pad Fig. 1.11 Head Support
Fig. 1.3 Buckle Adjustment Lever
Fig. 1.4 Webbing Adjuster Fig. 1.12 Lock-off
Fig. 1.5 Recline Adjustment Fig. 1.13 Instruction Manual
Storage Handle Compartment
Fig. 1.6 Crotch Strap Fig. 1.14 Base
Fig. 1.7 Shoulder Strap Fig. 1.15 Back Slot
Fig. 1.8 Infant Insert Fig. 1.16 Seat Slot
Fig. 1.9 Body Portion
Outer soft goods include Seat Pad, Crotch Pad, Head Support and Infant
Insert. Please make sure there are no missing parts. Please contact the
retailer if anything is missing.
GB
Congratulations
You have purchased a high quality﹐ fully certified child
safety child restraint. This product is suitable for the use
of children weighing UNDER 36kg (approximately 12
years old or under).
Carefully read this Instruction Manual and follow the
installing steps because this is the ONLY way to protect
your child from serious injury or death in case of an
accident﹐ and to provide comfort to your child while
using this product.
Keep this instruction manual for future reference.
Please Confirm
Make sure that your vehicle is equipped with 3-point
retractor safety-belt.
Seat belts may be different in design and length
according to maker﹐ manufacturing date﹐ and type of the
vehicle. This child restraint is only suitable for use in the
listed vehicles fitted with 3-point retractor safety-belts
and UN ECE regulation 16 or other equivalent standards.
This child restraint is approved to UN ECE regulation 44﹐
04 series of amendments.
This child restraint is not suitable for use in the vehicles
fitted with Lap Belts.
! Please keep the instruction manual in the storage
compartment of the rear cover for future reference.
