5
6
Recline Adjustment
see images
3
-
4
Press the recline adjustment handle,
and adjust the child restraint to the
proper position.
3
The recline angles are shown as
4
The recline angle 5 is for baby mode,
it is marked as blue triangles.
There are four recline angles 1-4 for
toddler mode, they are marked as red
triangles.
There are four recline angles 1-4 for
junior mode, they are marked as red
triangles.
Angle indication: with top and bottom
triangles aligned.
Use Side Impact Shield
see images
1
-
2
!
Must open the side impact shield
plastic to protect the child more
safely. The side impact shield not
on the same side of the vehicle
door can be closed to allow more
seating space.
1
2
1
2
3
2
1
4
3
2
1
5
4
