Jon-Don R340 - English; Table of Contents; Specifications

2
www.jondon.comToll-Free 1-800-556-6366
Table of Contents
Introduction ............................................................................ 1
1. Safety Certications ....................................................... 2
2. Specications .................................................................2
3. Operation ........................................................................3
3.1 Transporting .............................................................. 3
3.2 Electrical Requirements ........................................... 3
3.3 Condensate Removal ............................................... 3
3.4 Ducting ......................................................................3
3.5 Defrost Cycle .............................................................3
3.6 Power Button ............................................................3
3.7 Purge Button .............................................................3
3.8 Hour Meter ................................................................4
3.9 Hours Button ............................................................4
3.10 Defrost Light ...........................................................4
4. Maintenance ...................................................................4
4.1 Air Filter ..................................................................... 4
4.2 Storage ......................................................................4
5. Service ............................................................................. 4
5.1 Technical Description ............................................... 4
5.2 Troubleshooting ........................................................ 5
5.3 Air Mover ...................................................................5
5.4 Thermistor .................................................................6
5.5 Condensate Pump .................................................... 6
5.6 Float Safety Switch ................................................... 6
6. Wiring Diagram ..............................................................7
7. Service Parts ................................................................... 8
Warranty .......................................................................... 9
Serial No. ___________________________
Purchase Date ______/______/_____
Dealer’s Name ___________________________________
1 Safety
The R340 conforms to unied standard UL 60335-2-40
• Never operate a unit with a damaged power cord. If
the power cord is damaged it must be replaced by the
manufacturer, its service agent, or similarly qualied person
in order to avoid a hazard.
• The unit shall be installed in accordance with national
wiring regulations.
• Do not obstruct the air intake and exhaust. Maintain a .3
m (1 ft) clearance around the air intake and exhaust.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play
with the appliance.
2 Specifications
Part No. # OE-R340-EA
Power 9.2 amps, 120 VAC, Grounded
Water 145 pints/day @ AHAM (80°F, 60%)
Removal
Blower 310 CFM without external ducting
Refrigerant 1 lb, 14 oz. R-410A
Charge
Operating 33°F to 110°F
Range
Filters: 2” x 12” x 12” Pleated Media MERV-11
Duct Intake – 12” Flex-Duct
Options Outlet – 10” Lay-Flat
Warranty Five years;
1st year 100% of Parts, Labor and Shipping
within the continental United States.
2nd-5th year 100% of sealed refrigeration
system parts.
Dimensions
Unit Shipping
Width 20” 21”
Height 33.5” 35.25”
Depth 20” 21”
Weight 115 lbs 125 lbs
Patent 7,246,503
D570,988
8,069,681
Read the operation and maintenance instructions
carefully before using this unit. Proper adherence to these
instructions is essential to obtain maximum benet from
your R340 dehumidier.
• It is designed to be used INDOORS ONLY.
• If used in a wet area, plug it into a GROUND FAULT
INTERRUPTER.
• DO NOT use the R340 as a bench or table.
• It must always be used in the upright position.
