Document 10000028013-DOC-000-00-EN
AutoTemp 56
Fig. 0-6 Controller AutoTemp 56
1 Heating and chilling functions
2 Stirrer functions
3 Water filling functions
4 Program functions
5 Keys for tilt operation
6 Arrow keys
7 Keys and LED’s for heating and chilling modes
8 “Standby” key
General control methodology
In general, a function key is pressed so that the associated display flashes, indicating that the value can
be altered using the arrow keys. The large arrows change the value in large steps and the small arrows
change the value in small steps. If the key is held down, the value will increase/decrease at an increasing
rate. This enables the required setting to be achieved by simply pressing a few keys.
Fig. 0-7
For all relevant function groups there is an ON/OFF key and an LED.
Pressing alternately activates and deactivates the function.
The LED will illuminate when the function is activated.
Parameter settings
The operation of the kettle depends on a number of parameters, e.g. the volume of the kettle, which must
be set correctly in order for the kettle to work. These parameters are set in the sections ‘User menu’ and
‘Factory settings menu’.
Error codes
The system continually monitors many factors in order to protect the machine and the user. If the ma-
chine detects a fault, an error code will be shown, as described in the section Error codes
