WARNING: Ensure that both thumbscrews and the adjuster locking
pins are engaged before flying to prevent the pilot from
shifting backwards. This could result in loss of aircraft
control.
7.2.6.3 De-misting control (Manual option)
For aircraft without the ergonomic control system, the cabin and
demisting ventilation system is manually adjustable via an organ stop on
the instrument panel.
To adjust the ventilation, push or pull the organ stop as follows:
• Pulling the organ stop towards the pilot increases airflow.
• Pushing the organ stop towards the instrument panel decreases
airflow.
Figure 7.2-11: De-misting valve open
Organ
