JS-MD 3
Aircraft Flight Manual
MD10-AFM-00-001
Issue: 01
Rev. 00
Rev. Date: 14-Feb-20
Page 7-30
filled to reach total capacity. Both tanks must be drained by removing
sealing vinyl stickers from the bottom hole(s)
Figure 7.8-7 (SN080 and onwards)
.
Filling hole (Left)
Vent hole (Right)
Non-expendable
water ballast (Upper)
Non-expendable
water ballast (Lower)
Filling hole (Left)
Vent hole (Right)
