English – 35
Engine
Cylinder capacity, cm
3
Cylinder bore mm
Stroke length, mm
Idling speed, rpm
Recommended max.
speed, rpm
Power, kW/ rpm
Ignition system
Manufacturer
Type of ignition system
Spark plug
Electrode gap, mm
Fuel-/lubrication system
Fuel tank capacity, litres
Oil tank capacity, litres
Type of oil pump
Weight
Weight without fuel, bar and chain, kg
TECHNICAL DATA
2033T
33
37
30
2 900
11 000
1,2/ 7 000
Walbro
WP404
Champion RCJ 8
0,5
0,23
0,15
Automatic
3,1
Noise levels
Equivalent (see note 1) noise pressure level
at the user's ear, measured according to
relevant international standards, dB(A).
Equivalent (see note) noise power level,
measured according to relevant international
standards, dB(A).
Vibration levels
(See note 2)
Front handle m/s
2
Rear handle m/s
2
Chain/bar
Standard bar length, inches/cm
Recommended bar lengths, inches/cm
Usable cutting length, inches/cm
Chain speed at max.power, m/sec
Pitch, inch/mm
Thickness of drive link, inch/mm
Number of teeth on drive sprocket
Bar and chain combinations
The following combinations are CE approved.
Bar Chain
Length, Pitch, Max. no of teeth
inches inches on tip sprocket
12 3/8 7 T Jonsered S 36/
Oregon 91 VG
14 3/8 7 T Jonsered S 36/
Oregon 91 VG
2033T
95,9
102
4,5
7,0
14"/35
12-14"/30-35
11"/28
13,3
3/8"
0,050"/1,27
6
Note 1: Equivalent noise level is, according to ISO 7182 and
ISO 9207, calculated as the time-weighted energy total for
noise levels under various working conditions with the following
time distribution: 1/3 idle, 1/3 max. load, 1/3 max. speed.
Note 2: Equivalent vibration level is, according to ISO 7505,
calculated as the time-weighted energy total for vibration levels
under various working conditions with the following time
distribution: 1/3 idle, 1/3 max. load, 1/3 max. speed.
1
5
L
Type Inch Inch/mm Inch/mm Angle Angle Angle Inch/mm Inch/cm: dl
91VG 3/8" 0,050"/1,3 5/32" /4,0 85° 30° 0° 0,025"/0,65 12"/30:45 14"/34:52
/S 36 16"/41:56
EU declaration of conformity (Only applies to Europe)
(Directive 89/392/EEC, Annex II, A)
We, Jonsered, S-561 82 Huskvarna, Sweden, tel. +46 36-146500, declare under sole responsibility that the chain saw
Jonsered 2033T from the serial numbers T001001 and onwards, is in conformity with the following standards or other
normative documents following the provisions in the COUNCIL’S DIRECTIVES:
- of June 14 1989 “relating to machinery” 89/392/EEC and applicable supplements.
- of May 3 1989 “relating to electromagnetic compatibility” 89/336/EEC, and applicable supplements.
The following standards have been applied: EN292-2, ISO/DIS 11682-2. The supplied chain saw conforms with the
example that underwent EU type approval.
Registered body: 0404, SMP Svensk Maskinprovning AB, Fyrisborgsgatan 3, S-754 50 Uppsala, Sweden, has carried
out EU type approval in accordance with article 8 section 2c. The EU type approval certificate, is numbered 404/97/490.
Huskvarna February 24, 1998
Anders Ströby, Product manager.
