Jonsered 2036 Workshop Manual

115
Tools
9.
9
Contents
Oil pump 116
Generator 116
Clutch 117
Vibration damper 117
Crankshaft 118
Ball bearing 118
Sealing ring 119
Cylinder and piston 120
Ignition system 120
Crankcase 121
Tightness testing 122
Chain brake 122
Fuel pick-up 122
Workshop equipment 123

Jonsered 2036 Specifications

General

Displacement	36.3 cm³
Power output	1.5 kW
Weight (excl. cutting equipment)	4.2 kg
Chain pitch	3/8"
Recommended bar length	35-40 cm
Vibration level	4.5 m/s²
