Jonsered 2036 Workshop Manual

3
Safety equipment
1
1.
Contents
Dismantling 4
Disassembly 4
Fitting 6
Dismantling, mod. 2054/2055 7
Fitting, mod. 2054/2055 9
Dismantling, mod. 2077/2083 10
Fitting, mod. 2077/2083 11
Checking of automatic function 12
Checking of brake action 13
Chain catcher 13
Throttle lock 13

Jonsered 2036 Specifications

General

Displacement	36.3 cm³
Power output	1.5 kW
Weight (excl. cutting equipment)	4.2 kg
Chain pitch	3/8"
Recommended bar length	35-40 cm
Vibration level	4.5 m/s²
