Jonsered 2036 Workshop Manual

77
7
Cylinder and piston
7.
Contents
Dismantling
General 78
Mod. 2036/2040, Mod. 2041/2045/2050 78
Fitting
Mod. 2036/2040, Mod. 2041/2045/2050 80
Dismantling
Mod. 2054/2055 82
Fitting
Mod. 2054/2055 83
Dismantling
Mod. 625/630/670, Mod. 2077/2083, Mod. 2095 84
Fitting
General 85
Decompression valve 85
Mod. 625/630/670, Mod. 2077/2083, Mod. 2095 85
Cleaning, inspection 87
Analysis and procedure 87
Service tips 92
Wear tolerances 92

Jonsered 2036 Specifications

General

Displacement	36.3 cm³
Power output	1.5 kW
Weight (excl. cutting equipment)	4.2 kg
Chain pitch	3/8"
Recommended bar length	35-40 cm
Vibration level	4.5 m/s²
