Jonsered 2036 Workshop Manual

16
1
2
Safety equipment
1
Fitting mod. 2095
Replace damaged or worn parts and fit in
the reverse order to dismantling.
Fitting mod. 2095
Replace damaged or worn parts.
Fit in the reverse order to dismantling.
Pay attention to the following:
● The spring’s straight shank should be
fitted in the throttle control lock (1).
● Make sure the throttle wire housing is
well pressed down in the recess (2).
● Check that the short-circuiting cable
sits in the recess so that it is not
clenched when the handle half is
screwed tight.

Jonsered 2036 Specifications

General

Displacement	36.3 cm³
Power output	1.5 kW
Weight (excl. cutting equipment)	4.2 kg
Chain pitch	3/8"
Recommended bar length	35-40 cm
Vibration level	4.5 m/s²
