38 – English
TECHNICAL DATA
Bar and chain combinations
The following cutting attachments are approved for the models Jonsered CS 2166,CS 2172 and CS 2172WH.
Saw chain filing and file gauges
Bar Chain
Length, inch Pitch, inch Gauge, mm Max. nose radius Type
Length, drive links
(no.)
16 3/8 1,5 11T Jonsered H42 60
18 3/8 1,5 11T Jonsered H42 68
20 3/8 1,5 11T Jonsered H42 72
24 3/8 1,5 11T Jonsered H42 84
28 3/8 1,5 11T Jonsered H42 92
