Jonsered CS 2238 - Accessories

unit
CS 2234
(P02138JN)
CS 2238
(P02138JN)
Product dimensions
Weight (excluding cutting equipment) kg (lb) 4.9 (10.8) 4.9 (10.8)
Oil tank volume cm
3
200 200
Fuel and lubrication system
Oil pump capacity at 9000 min
-1
ml/min 7 7
Type of oil pump Automatic Automatic
Saw chain and guide bar
Standard guide bar length cm (in) 35 (14), 40 (16) 35 (14), 40 (16)
Recommended bar lengths cm (in) 35 (14), 40 (16) 35 (14), 40 (16)
Usable cutting length cm (in)
34 (13.5), 39
(15.5)
34 (13.5), 39
(15.5)
Maximum saw chain speed m/s 22,3 22,3
Saw chain pitch mm (in) 9.52 (3/8) 9.52 (3/8)
Thickness of drive links (gauge) mm (in) 1.3 (0.05) 1.3 (0.05)
Type of drive sprocket Spur Spur
Number of drive sprocket teeth 6 6
Accessories
Guide bar and saw chain
combinations
The cutting attachments below are approved for the
models Jonsered CS 2234 and CS 2238.
Guide bar Saw chain
Length, cm (in) Pitch, mm (in) Gauge, cm (in) Max. nose radi-
us
Type Drive link count
35 (14) 9.52 (3/8) 1.3 (0.050) 7T H37, UC 83 G 52
40 (16) 9.52 (3/8) 1.3 (0.050) 7T 56
45 (18) 9.52 (3/8) 1.3 (0.050) 7T 62
298 - 004 - 14.10.2019 23
