TECHNICAL DATA
Technical data
CS 2156 CS 2159
Engine
Cylinder volume, cu.in/cm
3
3,45/56,5 3,60/59,0
Cylinder bore, inch/mm 1,81/46 1,85/47
Stroke, inch/mm 1,34/34,0 1,34/34,0
Idle speed, rpm 2700 2700
Power, kW/ rpm 3,2/9600 3,0/9 000
Ignition system
Manufacture SEM SEM
Type of ignition system CD CD
Spark plug Champion RCJ 7Y/
NGK BPM7A
Champion RCJ 7Y/
NGK BPM7A
Electrode gap, inch/mm 0,02/0,5 0,02/0,5
Fuel and lubrication system
Manufacturer of carburettor Walbro Walbro
Carburettor type HDA 199/
HDA 191
HDA 199/
HDA 191
Fuel tank capacity, US pint/litre 0,68 0,68
Oil pump capacity at 9,000 rpm, ml/min 6-17 6-17
Oil tank capacity, US pint/litre 0,80/0,38 0,80/0,38
Type of oil pump Automatic Automatic
Weight
Chain saw without bar or chain, empty tanks, Lbs/kg 12,3/5,6: CS 2156,
CS 2156 C
12,5/5,7: CS 2156 CWH
12,3/5,6: CS 2159,
CS 2159 C
12,5/5,7: CS 2159 W,
CS 2159 WH,
CS 2159 CWH
Chain/bar
Standard bar length, inch/cm 15”/38 15”/38
Recommended bar lengths, inch/cm 13-20"/33-50 13-20"/33-50
Usable cutting length, inches/cm 12-19"/31-48 12-19"/31-48
Chain speed at max. power, m/sec 21,4 20
Pitch, inch/mm 0,325"/8,25 0,325"/8,25
3/8" /9,52 3/8" /9,52
Thickness of drive links, inch/mm 0,058/1,5 0,058/1,5
Number of teeth on drive sprocket 7 7
