Jonsered CS2255 User Manual

40 – English
TECHNICAL DATA
Bar and chain combinations
The following cutting attachments are approved for the model Jonsered CS 2255.
Saw chain filing and file gauges
Bar Chain
Length, inch Pitch, inch Gauge, mm Max. nose radius Type
Length, drive links
(no.)
13 0,325 1,5
10T Jonsered H25
56
15 0,325 1,5 64
16 0,325 1,5 66
18 0,325 1,5 72
15 3/8 1,5
11T Jonsered H42
56
16 3/8 1,5 60
18 3/8 1,5 68
20 3/8 1,5 72

Jonsered CS2255 Specifications

General

Cylinder Displacement	55.5 cm³
Chain Pitch	3/8"
Recommended Bar Length	13-20 in
Chain Gauge	0.05"
Vibration Level (front/rear handle)	3.5/4.1 m/s²
