6 – English
Customer responsibilities
• Read and observe the safety rules.
• Follow the maintenance schedule in this manual. Any
maintenance other than that described in this manual
must be carried out by your servicing dealer (retailer).
PRESENTATION
The Lawn mower
Serial number:
Date of purchase:
The model and serial numbers will be found on a decal
attached to the rear of the lawn mower housing. You
should record both serial number and date of purchase
and keep in a safe place for future reference.
Product specifications
Gasoline Capacity and
Type
1.09 Quarts / 1.03 Liters
(Unleaded Regular Only)
Oil Type (API SG-SL)
SAE 30 (above 0°C / 32°F)
SAE 5W-30 (below 0° /
32°F)
Oil Capacity 15 Ounces
Spark Plug (Gap: 0.020’’ /
0.5mm)
AUTOLITE 3924
Blade Bolt Torque 35-40 ft. Ibs. (47-54 Nm)
