Always operate with the deflector or grasscatcher in the correct position.
Always stop the engine before removing the grasscatcher or adjusting the height of cut.
Never place your hands or feet underneath the deck or into the grass discharge chute while
the engine is running.
SAFETY PRECAUTIONS
Before mowing, remove all foreign objects from the lawn
which may be thrown by the machine. While mowing,
stay alert for any foreign objects which may have been
missed.
Never lift the rear of the mower while starting the engine
or during normal operation.
Never place your hands or feet underneath the deck or into
the rear discharge chute while the engine is running.
DESCRIPTION
ASSEMBLY OF GRASS CATCHER
ASSEMBLY HANDLES (upper)
MULCHING CAP INSERTION (for the models where it is included only)
To cut the grass with the mulching system (no grass collection), lift the rear deflector panel and insert the cap
by fixing it with the spring as shown in the figure.
ADJUSTMENT OF CUTTING HEIGHT
ASSEMBLY HANDLES (lower)
ASSEMBLY DEFLECTOR (if not already assembly)
Assembly deflector ,only for the models with this equipment (Fig.CVII)
ADJUSTMENT OF HANDLES
1 Upper handles
2 Fuel-enrichment pump
3 Fastening knobs for upper handles
4 Grass catcher
5 Oil filler cap
6 Oil drain plug
7 Deck
8 Adjusting levers for cutting height
9 Spark plug
10 Fuel cap
11 Engine start-grip
12 Rear deflector
13 Throttle lever
14 Engine stop lever
15 Reduction gear
16 Touch-N-Mow handle
17 Touch-N-Mow key
18 Clutch lever
3
