15
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
1 532 19 25-56 Mower Housing Assembly
2 872 14 05-06 Bolt Carriage 5/16-18 x 3/4
3 532 13 80-17 Bracket Asm Fr. Sway Bar
4 532 19 25-68 Bracket Deck Sway Bar 38"/42"
5 532 12 46-70 Retainer Spring
6 532 17 80-24 Bar Sway Deck
7 873 80 05-00 Nut Lock Hx w/Ins. 5/16-18 unc
8 532 19 30-03 Bolt 3/8-24 x 1.25 Gr. 8
11 532 19 39-57 Blade Mower
13 532 19 28-72 Shaft Assembly, Mandrel, Vented
14 532 18 72-81 Housing, Mandrel, Vented
15 532 11 04-85 Bearing, Ball, Mandrel
18 872 14 05-05 Bolt Rdhd Sqnk 5/16-18 x 5/8
19 532 13 28-27 Bolt, Shoulder
20 532 40 00-95 Baffle Vortex Front
21 873 68 05-00 Nut
23 532 19 25-57 Bracket, Mower Deflector
24 532 10 53-04 Cap, Sleeve
25 532 19 70-26 Spring, Torsion, Deflector
26 532 11 04-52 Nut, Push
27 532 40 14-72 Shield, Deflector
29 532 13 14-91 Rod, Hinge
30 532 17 39-84 Screw Thdrol.
31 532 18 76-90 Washer, Spacer
32 532 15 35-32 Pulley, Mandrel
33 532 40 02-34 Nut, Toplock
36 532 13 14-94 Pulley, Idler, Flat
37 532 19 31-98 Pulley Idler Flat
40 873 68 06-00 Nut, Crownlock 3/8-16 unc
45 532 12 47-88 Retainer
55 532 13 38-40 Idler Arm Assembly
56 532 16 57-23 Spacer, Retainer
67 532 10 69-32 Knob
68 532 19 32-14 V-Belt
72 532 19 32-16 Spring Brake Return
89 819 13 13-11 Washer 13/32 x 13/16 x 11 Ga.
107 532 13 35-02 Spacer Retainer
108 532 13 35-03 Stiffener, Idler Arm
122 532 41 01-89 Rod, Brake LH
123 532 41 01-90 Rod, Brake RH
144 532 19 34-14 Keeper Belt Idler Tension
148 532 16 90-22 Spring Return Idler
149 532 16 58-98 Retainer Spring Yellow
150 819 09 12-10 Washer 9/32 x 3/4 x 10 Ga.
152 532 19 32-35 Clutch Cable 38"/46"
158 817 72 04-08 Screw Hex Thd Cut 1/4-20 x 1/2
185 532 18 82-34 Head Asm Cable Clutch
186 817 49 06-44 Screw Hex Wsh Thdrol
3/8-16 x 2-3/4
187 532 19 34-12 Keeper Belt
188 532 16 58-91 Bolt Carriage Idler
189 532 19 25-59 Stand, Brake
190 532 19 25-60 Arm, Brake
191 532 19 25-61 Spacer, Brake
193 532 19 34-13 Keeper Belt Rh Mandrel
194 532 19 41-05 Guard Brake
195 819 13 32-10 Washer
208 817 67 06-08 Screw Thdrol 3/8 - 16 x 1/2
214 532 19 37-82 Bolt/Washer Asm 5/16-18
- - 532 19 25-58 Brake Assembly (Includes Stand,
Arm and Guard Components)
- - 532 19 28-70 Mandrel Assembly (Includes hous-
ing, shaft assembly, and bearing
only - pulley/nut/washer and blade
bolt/washers not included)
- - 532 43 20-31 Replacement Mower, Complete
TRACTOR - - MODEL NO. LT2113 (96011026604), PRODUCT NO. 960 11 02-66
MOWER DECK
