5
1 532 16 34-65 Battery
2 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4
8 532 17 66-89 Box Battery Fender
16 532 17 61-38 Switch Interlock
21 532 18 37-59 Harness Headlight
22 532 00 41-52 Bulb.
24 532 42 12-97 Cable Battery 8 Ga w/44 wire Red
25 532 42 12-99 Cable Battery 6 Ga 11" Red
26 532 17 51-58 Fuse
27 873 51 04-00 Nut Keps Hex 1/4-20 unc
28 532 42 12-98 Cable Ground 6 Ga 12" black
29 532 19 27-49 Switch Seat
30 532 19 33-50 Switch Ignition
33 532 41 19-35 Key/Chain
34 532 11 07-12 Switch Light/Reset
40 532 19 74-28 Harness Ignition
41 871 11 04-08 Bolt Blk Fin Hex 1/4 - 20 x 1/2
42 532 13 15-63 Cover Terminal Red
43 532 19 25-07 Solenoid
79 532 17 52-42 Socket Asm. Bulb Twistlock
90 532 18 04-49 Cover Terminal Battery
92 532 19 66-15 Harness Pigtail Console ROS
93 532 19 25-40 Screw Plastite 10-14 x 2.0
94 532 19 18-34 Module Reverse ROS
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches.
1 inch = 25.4 mm.
TRACTOR - - MODEL NO. LT2113 (96011026604), PRODUCT NO. 960 11 02-66
ELECTRICAL
32
