Jonsered LT2113 - Page 8

7
1 532 17 46-19 Chassis
2 532 17 65-54 Drawbar
5 532 15 52-72 BumperHood/Dash
9 532 19 48-22 Dash
10 872 14 06-08 Bolt, Carriage 3/8-16 x 1
11 532 17 49-96 Dashboard, Panel LH
13 532 18 69-52 Dashboard, Panel RH
17 532 18 67-07 Hood Pnt
18 532 18 49-21 BumperHood
24 874 78 06-16 Bolt, Hex Head, Fin. 3/8-16 x 1 Gr. 5
25 819 13 13-12 Washer 13/32 x 13/16 x12 Ga.
26 873 80 06-00 Nut Lock Hex w/Ins. 3/8-16 unc
28 532 18 57-06 Grille
29 532 18 58-46 Lens
30 532 19 57-70 Fender
31 532 13 66-19 Fender Bracket
33 532 18 11-93 Footrest, LH
34 532 18 11-94 Footrest, RH
35 872 11 06-06 Bolt 3/8-16 X 3/4
37 817 49 05-08 Screw Thdrol 5/16-18 x 1/2
38 532 17 57-10 Bracket Asm. Pivot Mower Rear
39 532 40 78-07 Bracket Pivot Laser/Elite
64 532 15 47-98 Dash Lower
142 532 17 57-02 Plate Reinforcement
145 532 40 91-67 Rod Pivot Chassis/Hood
205 817 49 06-08 Screw Thdrol 3/8-16 x 1/2
207 817 67 05-08 Screw Thdrol 5/16-18 x 1/2
208 817 67 06-08 Screw Thdrol 3/8-16 x 1/2
209 817 00 06-12 Screw Hexwsh Thdr 3/8-16 x 3/4
212 532 18 35-50 Insert Lens Reflective
278 532 41 63-58 Screw #10 x 0.750
- - 532 00 54-79 Button Plug
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches.
1 inch = 25.4 mm.
TRACTOR - - MODEL NO. LT2113 (96011026604), PRODUCT NO. 960 11 02-66
CHASSIS AND ENCLOSURES
39
39
