Jonsered LT2216 Spare Parts

7
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
KEY PART
NO. NO. DESCRIPTION
5 532 40 95-97 Dash
14 532 42 43-32 Hood
18 532 42 65-11 Grille
34 532 19 61-25 Plate Engine
36 817 06 05-12 Screw 5/16-18 x 3/4
37 532 42 43-35 Fender
52 873 68 05-00 Nut Lock 5/16-18
58 532 41 22-80 Drawbar Upper
68 817 49 05-08 Screw Thdrol 5/16-18 x 1/2
130 532 41 63-58 Screw #10 x 0.750 BOS THREAD
150 532 40 02-67 Duct Heat Hood
151 532 18 75-68 Bracket Pivot
152 532 19 95-35 Shield Browning
153 532 40 97-40 Lens Bar
159 817 00 06-12 Screw Hexwsh Thdrol 3/8-16 x 3/4
175 532 19 94-72 Crossmember
176 532 40 07-76 Screw 10-24 x 5/8 Wshd Qdrx
177 532 19 52-28 Bushing Steering
180 532 41 50-63 Chassis
181 532 40 47-96 Bushing Mtg. Fender Crgo.
182 532 40 71-76 Dash Lower
183 874 78 05-20 Bolt Fin Hex 5/16-18 x 1-1/4
189 817 00 05-12 Screw 5/16-18 x 3/4
191 532 41 65-02 Reflector RH
194 873 90 05-00 Nut Lock Hex Flange 5/16-18
196 532 41 45-79 Console Asm. Deck Lift
202 532 42 33-17 Vent Side Hood RH
203 532 42 33-16 Vent Side Hood LH
213 874 76 05-12 Bolt 5/16-18 unc x 3/4
217 532 40 91-67 Rod Pivot Hood
218 532 19 63-95 X-Piece Hood Stop
225 532 42 32-28 Bumper
228 532 19 51-61 Stud Fastener
235 532 40 61-29 Spacer Fender
236 873 93 05-00 Nut Center Lock 5/16-18
237 532 40 37-04 Plug Mount Cargo
287 817 60 04-06 Screw Hex Wash 1/4-20 x 3/8
297 532 40 18-27 Reflector Insert LH
TRACTOR - - MODEL NO. LT2216 (96041010101), PRODUCT NO. 960 41 01-01
CHASSIS AND ENCLOSURES
39
39
