Jonsered RS51 User Manual

18 – English
WHAT IS WHAT?
15. Air filter cover
16. Clutch cover
17. Handlebar adjustment
18. Locking nut
19. Support flange
21. Drive disc
25. Socket spanner
26. Operator‘s Manual
27. Transport guard
28. Allen key
29. Carburettor screwdriver
30. Locking pin
31. Harness
33. Gearbox grease
1. Blade
2. Grease filler cap
3. Angle gear
4. Blade guard
5. Shaft
6. Handlebars
7. Throttle
8. Stop switch
9. Throttle trigger lock
10. Suspension for clearing saw
11. Cylinder cover
12. Starter handle
13. Fuel tank
14. Choke
What is what on the clearing saw (RS51)?
JONSERED SERVICE
30
33
31
29
