Figure 1.1
Page 2
Assembling and Using your Stroller
Figure 2.1
Figure 2.2
!
CAUTION
Adult assembly is required for this product. This package contains small parts. Keep small
parts away from children during assembly. No Tools Required.
1 Unpacking the Product
• Carefully remove stroller and all parts from the box
and plastic bag.
• Remove any cardboard packing materials from the
stroller.
• Remove everything from the box and identify the
parts using Figure 1.1 (not to scale):
stroller, front wheel set (2), rear wheels (2), rear axle
and brake set, canopy, bumper bar, small washers
(2), spring washers (2), large washers (4), snap pins
(2), hubcaps (2) and documents [not shown]). Also,
extra rear wheel assembly parts may be included.
• Discard all packaging materials properly including
plastic coverings.
• DO NOT allow children to play with any packaging
materials.
2 Unfolding the Stroller
• Keep children away from stroller while unfolding.
• Orient the stroller with the handlebar facing upward
and closest to you.
• If necessary, release the folding lock located on the
right side by lifting the lock off of the extended rivet.
See Figure 2.1.
• Pull upwards on the handlebar until the stroller is
completely opened and the latching mechanism on
each side is engaged. See Figure 2.2.
NOTE: Be careful not to scratch the oor when
opening the stroller.
• Visually check and gently push downward on the
handlebar to ensure that the stroller is completely
opened and locked before ANY use of the product.
!
WARNING
ALWAYS keep children away from the stroller when
unfolding.
x2 x4 x2 x2
x2
small
washers
large
washers
spring
washers
snap
pins
hub
caps
