Page 8
11 Securing the Child
• There are three height adjustment positions for the
shoulder harness. Adjust the height to the closest
height above your child’s shoulders.
• To remove the shoulder harness, turn the plastic ends
sideways and push them through the slots in the
seatback. Reattach the harness at the proper height
by reinserting the plastic ends through the slots. See
Figure 11.1. Ensure both straps are the same height.
• To remove the crotch strap, turn the plastic end
sideways and push it through the slot in the seat bottom.
Reattach the crotch strap by pushing the plastic end
down through the slot.
• Remove the waist straps by sliding the strap through
the small opening in the metal D-ring, then pull the
strap away from the seat. See Figure 11.2. Reattach
by pushing the metal-D ring through the slot in the seat,
wrap the strap around the seat rear tube. Slide the
strap through the small opening of the metal D-Ring
and pull the strap to secure it to the tube. Repeat for the
other end of the strap
• To unlatch the buckle press the center button and
remove the male ends of each buckle.
See Figure 11.3.
• Carefully place the child in the seat with the shoulder
straps over their shoulders and chest. Then place the
crotch strap between the child’s legs.
• Bring the shoulder/waist buckles into the crotch buckle
until the shoulder/waist buckles snap into place.
See Figure 11.4.
• Tighten the waist belt to be snug around the child’s
waist.
• The shoulder, waist, and crotch straps may be adjusted
using the sliding buckles on these straps.
Figure 11.1
Figure 11.2
Figure 11.3
Figure 11.4
!
WARNING
Avoid serious injury from falling or sliding out.
Always use the safety harness.
12 Storage Basket
The maximum weight that can be carried in the storage
basket is 5 lbs. Excessive weight may result in a
hazardous unstable condition.
NOTE: The basket can be removed if desired by
unsnapping all of the snaps, opening the zipper in the
front and releasing Velcro® straps.
