Page 4
Figure 5.1
Figure 5.2
!
WARNING
Always make sure the wheel brakes are engaged when the stroller is not being pushed
so that the stroller will not roll away. Never leave stroller unattended, especially on a hill or
incline, as the stroller may tip over or slide.
Figure 4.1 Figure 4.2
Figure 6.1
5 Installing the Front Wheels
• Position the stroller so it is resting on the rear wheels
and the handlebar. Locate one front wheel set and
position the wheel set with the swivel lock tab facing
upward. Insert it onto a plastic post located at the
bottom front on one side of the stroller until an audible
click is heard. See Figure 5.1.
• Pull outward on the wheel set to ensure the wheel set is
installed properly.
• Repeat this procedure for the other wheel.
• To remove a front wheel set, squeeze the two tabs at
the bottom of the front wheel housing and slide the
wheel set off of the plastic post. See Figure 5.2.
6 Front Wheel Locks
• The front wheels can be either in swivel mode or locked
mode.
• To put each front wheel set into its locked mode, push
up on the locking tab located at the top of the wheel
housing and between the wheels. Be sure to lift the
locking tab all the way up until an audible click is heard.
See Figure 6.1.
NOTE: You may need to rotate the front wheel so the
swivel lock tab is facing the front of the stroller.
• To unlock each wheel and put it into swivel mode, push
down on the locking tab to disengage the lock.
To Next Page
