Page 7
10 Installing, Operating and
Removing the Canopy
• Stand behind the stroller with the stroller in the unfolded
position.
• Orient the canopy in front of the handlebar with the visor
towards the front of the stroller.
• Locate the plastic slide locks on the bottom of each side
of the canopy and slide them onto the plastic tting on
each side of the stroller just above the rear leg.
See Figure 10.1.
• Push each side of the canopy rmly down along the
tting until it cannot go any further.
• Fit each rear canopy apron around the back of each
seat.
• Attach the Velcro on each canopy apron to the Velcro®
on the sides and back of each seat. See Figure 10.2.
• Attach the Velcro® tabs at the top rear corners of the
canopy to the handle tubes just below the handlebar
foam. See Figure 10.3.
• Open the canopy by pulling forward on the front edge.
• The canopy and visor can be adjusted into several
positions ranging from fully closed to fully extended, or
any position in between. See Figure 10.4.
• The visor can be opened (or closed) by pulling (or
pushing) it from under the canopy.
• Note: The top rear portion of the canopy has a roll back
window. To open, pull the forward edge up, roll the ap
back and secure it using the elastic loop attachment.
• To close the canopy, push the front edge of the canopy
toward the rear of the stroller.
• To remove the canopy, undo the Velcro® attachments
on the sides and back of the seat and the handle tubes.
Then, slide the canopy up off of both ttings on the
sides of the stroller. See Figure 10.5.
Figure 10.1
Figure 10.2
Figure 10.3
Figure 10.4
Figure 10.5
