JOSAM laser AM
Measuring system
8
Turn angle gauge AM135
Description
Turn angle gauge AM135 is, together with the laser
projector, designed to measure the maximum turn,
toe-out on turn, and the fixed values for KPI and
caster.
Measuring scales can slide along the base.
(1) The measuring scale's 0-line.
(2) The intersectional point of the 0-line.
For measurement using turn angle gauges AM135,
the axles are lifted so that the wheel rolls freely
approx. 10 mm from the floor. The caster value
will be insignificantly altered.
