OPERATING MANUAL for
BRAKE UNITS
JB10/... JB16/... JB26/... JB40/... JB52/...
(Installation set)
JB
2 of 19
01.96/00/Scho
1 ELECTRICAL SAFETY
THE JB BRAKE UNIT CARRIES DANGEROUS VOLTAGE WHEN IT
IS CONNECTED TO THE MAINS.
THE JB BRAKE UNIT MUST BE EARTHED BY AN EARTH
CONDUCTOR CONNECTED TO THE PE EARTH TERMINAL OF THE
HEAT SINK.
DANGEROUS VOLTAGE MAY ALSO BE PRESENT EVEN WHEN
THE JB BRAKE UNIT IS SWITCHED OFF.
BEFORE STARTING WORK, CHECK THAT THE JB BRAKE UNIT IS
ISOLATED BY CHECKING THE CONNECTING TERMINALS WITH A
VOLTMETER.
Warning symbols
For your own safety, please pay particular attention to the
instructions marked with the following symbols:
Danger! High voltage
General warning
THE ELECTRICAL INSTALLATION
WORK MUST ONLY BE CARRIED OUT
BY AN AUTHORIZED QUALIFIED
CRAFTSMAN.
!
