jost JSK 39 - 6.2 Lubrication Instructions

6 Servicing and testing
6.2 Lubrication instructions
KSK37/051
2
1 1
3
4
5
6
1 Handle 2 Fifth wheel coupling plate 3 Lock jaw
4 Locking bar 5 Hinge joints and lever guide 6 Wearing ring
Lubricate areas marked in yellow:
Side of handle (1), hinge joints and lever guides (5).
Generously lubricate the top side (2) and completely fill the lubricating groove (except W version – the top plate liners do not have to
be greased; JOST top plate liners are resistant to lubricating greases).
Lubricate lock jaw (3) and locking bar (4) with the fifth wheel coupling closed.
With the standard version (not the low-maintenance version), the centre area around the wearing ring (6) must be completely filled
with grease (see marked area).
Grease specification: We recommend JOST high-performance lubricant (article no. SKE 013 440 000).
18 MUB 002 004 M01 (REV-C) 04-2019 JSK 36 & JSK 37
JOST IND (REV-A) 06-2019
JSK 39
(Ideal Fifth Wheel Coupler Picture)
1
2
4
3
4
5
6
(5).
.
