13
139681_R06 F 500 Oslo 1/20
F 500 Gaskets
Description Size Length
Top Cover 3/8 in. 3.5 ft.
Top Plate 3/8 in. 7 ft.
Smoke Outlet 1/4 in. 3 ft.
Ash Housing 1/4 in. 4 ft.
Ash Pan Door 3/8 in. 4 ft.
Front Door 3/8 in. 6 ft.
Left Side Door 3/8 in. 4.5 ft.
Glass 3/8 in. 5 ft.
7.0 Accessories
Only use accessories that are specifically designed
for the Jøtul F 500.
Firescreen - 129172
The Jøtul F 500 has been approved for use as an
open fireplace, with front doors open. This feature is
especially nice when the ambience of a fire is desired.
Some care should be taken when operating the stove
as a fireplace.
• Always have the firescreen in place, attached to
the stove front.
• Never over load the stove: For the best appearance
burn in the traditional three log configuration.
• Reminder, when burning the stove with the
screen in place, you are sacrificing efficiency for
aesthetics, and you will be consuming wood at a
much faster rate.
Warning: Operate your Jøtul F 500 with the front
doors fully open and the firescreen in place or
fully closed. Partially opened doors may result in
overfiring. Also, if doors are left partly open, gas
and flame may be drawn out of the stove opening,
creating risks from both fire and smoke.
Stove Gloves, pair - 157363
Heavy duty, flame retardant, with full gauntlet.
Universal Gasket Kit - 157050
This kit includes all the gasket material required for your
stove.
Outside Air Kit - 154335
Provision for outside air may be required by your local
building codes.
The outside air kit includes a 3 inch adapter used to connect an
air duct directly to the stove combustion chamber. The following
additional materials will be required:
A. The appropriate length of metallic flex pipe for a conduit of
the outside air.
B. A rain/weather resistant cap for the outside of the house.
C. A rodent screen - that is no larger than 1/4”(6,4mm) mesh.
Follow the instructions provided with the kit.
Please be aware that provision of outside air to support
combustion will not necessarily eliminate performance issues
associated with negative pressure within the home or chimney
system.
Floor Bracket Kit - 750304
Use of the floor bracket kit is required in all mobile home
installations to secure the stove to the floor. Complete installation
instructions and diagrams are supplied with each floor bracket kit.
Rear Heatshield - 154332
A stove rear heatshield has been specifically designed for
the Jøtul F 500 to reduce clearances off the rear of the
stove to combustible materials. Use of the heatshield does
not affect the clearance off the sides of the appliance.
See pages 17-18 for specific clearance requirements. Complete
installation instructions are supplied with the heatshield. No
other type of heatshield may be used on the rear of the Jøtul F 500.
Bottom Heatshield - 154330
A bottom heatshield has been specifically designed for the Jøtul
F 500 and is included with your stove. It is required in all alcove
installations. Use of the bottom heatshield does not affect the
floor protection requirements discribed on page 7 of this manual.
No other type of heatshield may be used on the bottom of the
Jøtul F 500.
Stove-top Thermometer - 5002
Jøtul recommends the use of a magnetic stove-top thermometer
to monitor the surface temperature of the stove. The optimum
surface temperature range for the most efficient, clean burn is
between 400° and 600°.
Side Door Lock Kit - 155850
The side load door must be locked to permit installation of the
F 500 in a corner or alcove constructed of combustible materials.
Leg Leveler Kit - 156096
Replacement Door Knob Kit - 155991
