Jøtul F 500 User Manual

2
139681_R06 F 500 Oslo 1/20
Table of Contents
Combustion Specifications,
Building Codes,
Safety Notices ..................................................................................3
1.0 Installation
1.1 Assembly before Installation ..........................4
1.2 Chimney Connector ..........................................4
2.0 Chimney Requirements
2.1 Masonry Chimneys ............................................5
2.2 Prefabricated Chimneys ..................................5
2.3 Chimney Height .................................................5
2.4 Wall Pass-throughs ...........................................5
3.0 Connecting to the Chimney
3.1 Masonry Chimney Thimbles .................................... 6
3.2 Hearthmount into a Masonry Fireplace ............... 6
3.3 Prefabricated Chimneys............................................ 6
4.0 Clearances to combustibles
4.1 Floor Protection .......................................................... 7
4,2 Clearances to Walls and Ceilings ........................... 7
4.3 Using Shields to reduce Clearances ...................... 7
4.4 Alcove Installation .................................................................8
4.5 MobileHome Installation .....................................................8
5.0 Operation
5.1 Combustion Efficiency .............................................. 8
5.2 CO Emissions .............................................................. 8
5.3 Wood Fuel and Performance ................................. 8
5.4 Air Flow and Control ................................................. 8
5.5 Break-in Procedure ................................................... 9
5.6 Starting and Maintaining a Fire ........................................9
5.7 Creosote Formation and Removal ......................... 10
5.8 Adding Fuel ................................................................. 10
6.0 Maintenance
6.1 Annual Stove Inspection ......................................... 11
6.2 Ash Removal .............................................................. 11
6.3 Chimney System ...................................................... 11
6.4 Enamel Care ............................................................. 11
6.5 Glass Care ................................................................... 11
6.6 Glass Replacement ................................................... 11
6.7 Gaskets ........................................................................ 11
7.0 Accessories
Firescreen ............................................................................ 13
Outside Air Kit .................................................................... 13
Floor Bracket Kit ................................................................ 13
Rear Heatshield .................................................................. 13
Bottom Heatshield ............................................................ 13
Stove -Top Thermometer ................................................. 13
Side Door Lock Kit .............................................................. 13
8.0 Illustrations
Figures ..............................................................................................14-16
Clearance Chart and Diagrams ..................................................17-18
Parts Schematic and Listing ........................................................19-20
Appendix A (alternate floor protection)...................................21
9.0 Warranty Statement .............................................22
Standards
The Jøtul F 500 solid fuel heater has been tested and listed to :
U.S. Standards: ANSI/UL 737 and ANSI/UL 1482.
Canadian Standards:
CAN/ULC-S627-M00 and CAN/ULC-S628-M93
Certified Safety Tests performed by:
Intertek Testing Services, Middleton,
Wisconsin U.S.A.
Manufactured by:
Jøtul North America, Inc.
55 Hutcherson Drive
Gorham, Maine 04038, USA
and
Jøtul AS, P.O. Box 1411, Fredrikstad, Norway
Check Building Codes
WARNING !
THIS WOOD HEATER HAS A MANUFACTURER-
SET MINIMUM LOW BURN RATE THAT MUST
NOT BE ALTERED. IT IS AGAINST FEDERAL
REGULATIONS TO ALTER THIS SETTING
OR OTHERWISE OPERATE THIS WOOD
HEATER IN A MANNER INCONSISTENT WITH
OPERATING INSTRUCTIONS IN THIS MANUAL.
This heater meets the 2015 U.S.
Environmental Protection Agency’s
emission limits for wood heaters
manufactured after May 15, 2015.
This heater may not be sold
after May 15, 2020.
A French language version of fhis manual is available to
download at www. jotul. ca.
Télécharger la version française de ce manuel à l’adresse www.
jotul.ca.
NOTE: It is normal for a new, painted stove to emit
odor and smoke during initial fires, depending
upon temperatures over time. This is caused
by the curing of high temperature paint and
manufacturing materials. This condition can
be alleviated by opening a window or door to
provide additional ventilation. See Break-in
Procedure on page 9 for details.

Jøtul F 500 Specifications

General

Brand	Jøtul
Model	F 500
Category	Wood stove
Language	English
