16
139681_R06 F 500 Oslo 1/20
Fig.11
Fig.12
Fig.13
Fig. 14
Fig.15
1) Bend the flattened heat shield on the
perforations as shown, painted side down.
2) Use a 10 mm wrench to remove the
two bolts from the bottom of the ash
compartment.
3) Oriented as shown, use the two bolts to
attach the heat shield to the stove bottom.
Unpainted Side Up
To Next Page
